Description of aluminum end mill
The HRC55 aluminum dovetail milling cutter uses foreign first-class precision machine tools to grind unique spiral blade angles, which are sharp and wear-resistant, smooth cutting, and improve milling efficiency; The large groove design of the edge improves the metal removal rate and processing effect, reduces tool wear quickly and extends the service life of the tool; The seismic design of the four edge through the center edge reduces cutting resistance and improves resistance to collapse and damage; Standard straight handle, surface roughness, anti slip and knife drop design, making installation easier.
Carbide material introdution
Note：
If the following carbide T slot chamfer end mill cannot meet your requirements, we support OEM customized production. The diameter of 0.2mm to 25mm, the total length of 50mm to 200mm, 4F, 5F, 6F, 8F and logo can be customized, including inch size carbide T slot chamfer end mill. Please contact us to select or customize non-standard carbide T slot chamfer end mill according to your needs.
Instructions of Aluminum end mill
- Before using the carbide T slot chamfer end mill, please measure the tool deflection. If the tool deflection accuracy exceeds 0.01mm, please correct it before cutting.
- The shorter the carbide e extends out of the collet, the better. If the tool extends out longer, reduce the speed, feed speed or cutting amount.
- In case of abnormal vibration or sound during cutting, please reduce the speed and cutting amount until the situation is improved.
- Spray type and air jet type are preferred for steel cooling, which can improve the use effect of carbide end mill.
- Note: Not suitable for low speed machines such as rotary table and electric hand drill.
Applications
- Name: 55 degree tungsten carbide dovetail aluminum milling cutter
- Material: Tungsten steel hard alloy
- Suitable for machine tools: CNC machining centers, engraving machines, precision engraving machines, CNC machines, high-speed machines, and other machine tools
- Suitable for processing materials: cast iron, alloy steel, carbon steel, tool steel, quenched and tempered steel, stainless steel, copper, titanium alloy, etc
